PARAMETERS

SPECIFICATIONS

ENGINE

Power (HP)

39 hp category

No of cyl & cubic capacity (cc)

3 Cyl, 2146CC

Rated

2200

TRANSMISSION

GEAR BOX

8Forward + 2Reverse

LOCATION OF GEAR BOX SHIFTING

Center Shift

Rear Axle

Inboard Reduction

CLUTCH

Clutch

Single Clutch

ROAD SPEEDS

Speed Forward (kmph)

2.7-30.6

Speed Reveseve (kmph)

3.3-10.2

Maximum speed (kmph)

35

PTO

PTO

Single 540

540 PTO AT ENGINE RPM

1800

STEERING

Steering

Balanced Power Steering /
Mechanical Single drop arm option

Hydraulic lift capacity (kg)

1500kg

BRAKES

Brakes

Multi Plate Oil Immersed Disc Brake

TYRES

Front tyre

6.0 x 16

Rear Tyre

13.6X28

FRONT AXLE

Front Axle

Straight/Bend Axle option

WEIGHTS & DIMENIONS

Total Weight, kg

1850

Wheelbase (mm)

2010

Overall Length (mm)

3225

Overall Width (mm)

1750

Ground Clearance (mm)

400

Fuel tank

Capacity (ltrs)

50
